These Machines is specially customized for inspection at high line speeds, in packaging formats such as metal or composite tins, plastic containers or bottles. Flexible X-ray inspection solution designed to inspect a diverse range of applications. Because of its compact size, system is easy to install at line. Its inbuilt rejection system gives an accuracy of rejection with the sufficient storage.
PRODUCT DETAILS :
Machine Type | Food Scan X-Ray Machine |
Model Number | PSIPLXF200 |
Tunnel Size | 230X200mm |
Maximum Job Size Can Be Scan | Diameter 150X 200mmt |
Detector Type | Line Scan Detector |
Detector Area | Diameter 150X 200mmt |
Detector Type | Line Scan Detector |
Detector Area | 250mm |
X-Ray Generator Energy | 80kV 1mA |
Machine Size (LXWXH) | 1700X2000X2200mm |
Machine Weight | 400 KG |
Part Loading | Conveyor Based |
Display | 15” Touchscreen display |
Load Capacity | 20 kg |
Rejection System | Inbuilt Pneumatic pusher rejection |
Industry | Food, Pharma, Beverage, Pet Food, Nutraceuticals, Personal Care |
X-Ray Emission | < 1uSv/hr |
INSTALL APPLICATIONS :
Food
Rice Paddy
Bakery products
Beverage
Pet Food
Nutraceuticals
