We are Manufacturer, Supplier, Exporter of X Ray Baggage Scanner PSIPL 5030 B, Baggage Scanning Machines and our set up is situated in Pune, Maharashtra, India. It is use in Bank, Hotels, Corporate Offices, shopping-mall, hospitals, Prison, Factories, Museums, etc. This range is also known as X Ray Baggage Scanners / Inspection / Scanning / Security System, X Ray Luggage Scanners / Inspection / Scanning / Security System, Baggage Scanner / Inspection / Scanning / Security Machine, Luggage Scanner / Inspection / Scanning / Security Machines and our set up is situated in Pune, Maharashtra, India. It is use in Bank, Hotels, Corporate Offices, shopping-mall, hospitals, Prison, Factories, Museums, etc.
Model No. - PSIPL 5030 B
PRODUCT DETAILS :
| Tunnel dimensions | 500 x 300 MM |
| Penetration level | 30 MM steel |
| Multiple viewing modes | Organic, B/W, Negative |
| Rotation facility available | |
| Moveble or on site checking models or vehicle mountable also available ( optional ) |
TECHNICAL SPECIFICATIONS :
| Tunnel Size (mm) | 500(L) x 300(W) |
| Speed (m/s) Conveyor | 0.22 |
| Height (mm) Conveyor Max | 700 |
| Load (Kgs.) | 100 |
| Penetration | Typical 32mm steel, Guarantee 30mm steel |
| Power Consumption | Max 0.5 KVA |
| X-Ray Generator | 160 KV, oil cooling, from bottom to top |
| Wire Resolution | Typical AWG 38, Guarantee AWG 36 |
| X-Ray Leakage | Typical 3.0 μGy/h, Guarantee 3.5 μGy/h |
| Boundary Leakage | Typical 2.0 μGy/h, Guarantee 2.5 μGy/h |
| Operation Power | 220 VAC (±10%) 50±3Hz |
| Operation temperature / Humidity | 0 to 45 Degree C/ 5%-95% (noncondensing) |
| Unit Weight | Approx. 450 Kg. |
INSTALL APPLICATIONS :
Bank
Hotels
Corporate Offices
shopping-mall
hospitals
Prison
Factories
Museums
Resorts
Temples
Railways
Metros
Stadiums
Courts
Government Organizations
Embasis
Ports
Milletry-Offices
